Stream-Flo Remote Dart Delivery System with Fluid Bypass Manifold

Revolutionize your frac operations with precision and efficiency

Stream-Flo’s Remote Dart Delivery System combines state-of-the-art automation with robust engineering to streamline frac operations. Designed to enhance efficiency, safety, and flexibility, this system ensures precise delivery of frac darts or balls under high-pressure conditions while prioritizing operational safety and performance.

Key Features

High-Performance Delivery System
  • Regenerative Blower: Delivers consistent airflow for dart propulsion and retrieval.
  • Automated Launch Control: Speeds up the launch process while minimizing user interaction, reducing potential errors and delays.
  • Adaptable Design: Handles darts up to 3.90 inches in diameter and 12 inches in length.
Advanced Fluid Bypass Manifold
  • Efficient Flow Management: Redirects frac fluid behind darts for smoother delivery and higher flow rates.
  • Safety Focused: Isolates well pressure to protect equipment and personnel.
  • Customizable Configurations: Tailored to meet specific site and operational needs.
Enhanced Safety and Accessibility
  • Ground-Level Preloading: Darts/balls are preloaded at ground level, outside the “hot zone,” minimizing operator risk and ensuring ease of handling.
  • Temperature-Controlled Environment: The remote launch window provides a controlled environment for loading, programming, and charging smart darts at ground level. This reduces the risk of damage or operational issues compared to working above the frac equipment.
Flexible Packaging Options
  • Comprehensive Solutions: Stream-Flo offers pricing packages that combine the wellhead, frac system, and dart launcher into a single, cost-effective solution.

Benefits

Efficiency
  • Faster setup and operation reduce downtime.
  • Automated control and high fluid flow rates enable quicker dart deployment.
Safety
  • Ground-level dart preloading outside the hot zone reduces operator risk.
  • Temperature-controlled dart handling protects sensitive components and ensures reliable operation.
Custom Solutions
  • Configurable for varying site layouts and requirements.
  • Pricing packages available for a streamlined wellhead, frac, and launcher combination.

Capabilities and Specifications

Applications:
  • Hydraulic fracturing operations.
  • Multi-zone completions.
  • High-pressure, high-temperature environments.
Specifications:
  • Maximum Dart Diameter: 3.90 inches.
  • Maximum Dart Length: 12.0 inches.
  • Operating Pressure: Up to 15,000 psi.
  • Material Compatibility: Designed for harsh frac fluid environments.

Get Started Today

Stream-Flo's Remote Dart Delivery System is the ultimate solution for efficient, safe, and precise frac operations. Contact our experts to learn how we can tailor this system to your operational needs.
